Network Technology
GSM / CDMA / HSPA / EVDO / LTE / 5G
2G bands GSM 850 / 900 / 1800 / 1900
CDMA 800 / 1900
3G bands HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100
CDMA2000 1xEV-DO
4G bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 30, 32, 34, 38, 39, 40, 41, 42, 46, 48, 66 - A2886, A2888
1, 2, 3, 4, 5, 7, 8, 11, 12, 13, 14, 17, 18, 19, 20, 21, 25, 26, 28, 29, 30, 32, 34, 38, 39, 40, 41, 42, 46, 48, 53, 66, 71 - A2632, A2885
1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 30, 32, 34, 38, 39, 40, 41, 42, 46, 48, 66 - A2887
5G bands 1, 2, 3, 5, 7, 8, 12, 20, 25, 26, 28, 30, 38, 40, 41, 48, 66, 70, 77, 78, 79 SA/NSA/Sub6 - A2886, A2888
1, 2, 3, 5, 7, 8, 12, 14, 20, 25, 26, 28, 29, 30, 38, 40, 41, 48, 53, 66, 70, 71, 77, 78, 79, 258, 260, 261 SA/NSA/Sub6/mmWave - A2632
1, 2, 3, 5, 7, 8, 12, 14, 20, 25, 26, 28, 29, 30, 38, 40, 41, 48, 53, 66, 70, 71, 77, 78, 79 SA/NSA/Sub6 - A2885
1, 2, 3, 5, 7, 8, 12, 20, 25, 26, 28, 30, 38, 40, 41, 48, 66, 70, 77, 78, 79 SA/NSA/Sub6 - A2887
Speed HSPA, LTE, 5G, EV-DO Rev.A 3.1 Mbps
Launch
Announced 2022, September 07
Status Available. Released 2022, October 07
Body
Dimensions: 160.8 x 78.1 x 7.8 mm (6.33 x 3.07 x 0.31 in)
Weight: 203 g (7.16 oz)
Build: Glass front, glass back, aluminum frame
SIM Nano-SIM + eSIM + eSIM (max 2 at a time; International)
eSIM + eSIM (8 or more, max 2 at a time; USA)
Nano-SIM + Nano-SIM (China)
IP68 dust tight and water resistant (immersible up to 6m for 30 min)
Apple Pay (Visa, MasterCard, AMEX certified)
Display
Type: Super Retina XDR OLED, HDR10, Dolby Vision, 800 nits (HBM), 1200 nits (peak)
Size: 6.7 inches, 109.8 cm2 (~87.4% screen-to-body ratio)
Resolution: 1284 x 2778 pixels, 19.5:9 ratio (~458 ppi density)
Protection: Ceramic Shield glass
Platform
OS: iOS 16, upgradable to iOS 26
Chipset Apple A15 Bionic (5 nm)
CPU Hexa-core (2x3.23 GHz Avalanche + 4x1.82 GHz Blizzard)
GPU Apple GPU (5-core graphics)
Memory
Card slot: No
Internal: 128GB 6GB RAM, 256GB 6GB RAM, 512GB 6GB RAM
NVMe
Main Camera
Dual: 12 MP, f/1.5, 26mm (wide), 1/1.7", 1.9ยตm, dual pixel PDAF, sensor-shift OIS
12 MP, f/2.4, 13mm, 120ห (ultrawide)
Features: Dual-LED dual-tone flash, HDR (photo/panorama)
Video: 4K@24/25/30/60fps, 1080p@25/30/60/120/240fps, HDR, Dolby Vision HDR (up to 60fps), stereo sound rec.
Selfie camera
Single: 12 MP, f/1.9, 23mm (wide), 1/3.6", 1.0ยตm, PDAF
SL 3D, (depth/biometrics sensor)
Features: HDR
Video: 4K@24/25/30/60fps, 1080p@25/30/60/120fps, gyro-EIS
Sound
Loudspeaker Yes, with stereo speakers
3.5mm jack:No
Comms
WLAN: Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, hotspot
Bluetooth: 5.3, A2DP, LE
Positioning GPS, GLONASS, GALILEO, BDS, QZSS
NFC Yes
Radio: No
USB Lightning, USB 2.0
Features: Sensors Face ID, accelerometer, gyro, proximity, compass, barometer
Ultra Wideband (UWB) support
Emergency SOS via satellite (SMS sending/receiving)
Battery Type: Li-Ion 4323 mAh (16.68 Wh)
Charging: Wired, PD2.0, 50% in 30 min
15W wireless (MagSafe)
15W wireless (Qi2) - requires iOS 17.2 update
Misc: Colors Midnight, Purple, Starlight, Blue, Red, Yellow
Models: A2886, A2632, A2885, A2896, A2887, iPhone 14, SAR 1.14 W/kg (head): 1.15 W/kg (body)
SAR EU: 0.99 W/kg (head): 0.98 W/kg (body)
