Network
Technology: GSM / CDMA / HSPA / EVDO / LTE / 5G
2G bands: GSM 850 / 900 / 1800 / 1900
CDMA 800 / 1900
3G bands: HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100
CDMA2000 1xEV-DO
4G bands: 1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 30, 32, 34, 38, 39, 40, 41, 42, 48, 53, 66 - A3293
1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 32, 34, 38, 39, 40, 41, 42, 48, 53, 66, 71 - A3083
1, 2, 3, 4, 5, 7, 8, 11, 12, 13, 14, 17, 18, 19, 20, 21, 25, 26, 28, 29, 30, 32, 34, 38, 39, 40, 41, 42, 48, 53, 66, 71 - A3292
1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 30, 32, 34, 38, 39, 40, 41, 42, 48, 66 - A3294
5G bands: 1, 2, 3, 5, 7, 8, 12, 20, 25, 26, 28, 30, 38, 40, 41, 48, 53, 66, 70, 75, 76, 77, 78, 79 SA/NSA/Sub6 - A3293
1, 2, 3, 5, 7, 8, 12, 14, 20, 25, 26, 28, 29, 30, 38, 40, 41, 48, 53, 66, 70, 71, 75, 76, 77, 78, 79, 258, 260, 261 SA/NSA/Sub6/mmWave - A3083
1, 2, 3, 5, 7, 8, 12, 14, 20, 25, 26, 28, 29, 30, 38, 40, 41, 48, 53, 66, 70, 71, 75, 76, 77, 78, 79 SA/NSA/Sub6 - A3292
1, 2, 3, 5, 7, 8, 12, 20, 25, 26, 28, 30, 38, 40, 41, 48, 66, 70, 75, 76, 77, 78, 79 SA/NSA/Sub6 - A3294
Speed: HSPA, LTE, 5G, EV-DO Rev.A 3.1 Mbps
Launch
Announced: 2024, September 09
Status: Available. Released 2024, September 20
Body
Dimensions: 149.6 x 71.5 x 8.3 mm (5.89 x 2.81 x 0.33 in)
Weight: 199 g (7.02 oz)
Build: Glass front (Ceramic Shield), glass back, titanium frame (grade 5)
SIM · Nano-SIM + eSIM + eSIM (max 2 at a time; International)
· eSIM + eSIM (8 or more, max 2 at a time; USA)
· Nano-SIM + Nano-SIM (China)
IP68 dust tight and water resistant (immersible up to 6m for 30 min)
Apple Pay (Visa, MasterCard, AMEX certified)
Display
Type: LTPO Super Retina XDR OLED, 120Hz, HDR10, Dolby Vision, 1000 nits (typ), 2000 nits (HBM)
Size: 6.3 inches, 96.4 cm2 (~90.1% screen-to-body ratio)
Resolution: 1206 x 2622 pixels, 19.5:9 ratio (~460 ppi density)
Protection: Ceramic Shield glass (2024 gen), Mohs level 4
Platform
OS: iOS 18, upgradable to iOS 26
Chipset: Apple A18 Pro (3 nm)
CPU: Hexa-core (2x4.05 GHz + 4x2.42 GHz)
GPU: Apple GPU (6-core graphics)
Memory
Card slot: No
Internal: 128GB 8GB RAM, 256GB 8GB RAM, 512GB 8GB RAM, 1TB 8GB RAM
NVMe
Main Camera
Triple: 48 MP, f/1.8, 24mm (wide), 1/1.28", 1.22µm, dual pixel PDAF, sensor-shift OIS
12 MP, f/2.8, 120mm (periscope telephoto), 1/3.06", 1.12µm, dual pixel PDAF, 3D sensor‑shift OIS, 5x optical zoom
48 MP, f/2.2, 13mm (ultrawide), 1/2.55", 0.7µm, PDAF
TOF 3D LiDAR scanner (depth)
Features: Dual-LED dual-tone flash, HDR (photo/panorama)
Video: 4K@24/25/30/60/100/120fps, 1080p@25/30/60/120/240fps, 10-bit HDR, Dolby Vision HDR (up to 60fps), ProRes, 3D (spatial) video/audio, stereo sound rec.
Selfie camera
Single: 12 MP, f/1.9, 23mm (wide), 1/3.6", 1.0µm, PDAF, OIS
SL 3D, (depth/biometrics sensor)
Features: HDR, Dolby Vision HDR, 3D (spatial) audio, stereo sound rec.
Video: 4K@24/25/30/60fps, 1080p@25/30/60/120fps, gyro-EIS
Sound
Loudspeaker: Yes, with stereo speakers
3.5mm jack: No
Comms
WLAN: Wi-Fi 802.11 a/b/g/n/ac/6e/7, tri-band, hotspot
Bluetooth: 5.3, A2DP, LE
Positioning GPS (L1+L5), GLONASS, GALILEO, BDS, QZSS, NavIC
NFC: Yes
Radio: No
USB: USB Type-C 3.2 Gen 2, DisplayPort
Features
Sensors Face ID, accelerometer, gyro, proximity, compass, barometer
Ultra Wideband (UWB) support (gen2 chip)
Emergency SOS, Messages and Find My via satellite
Battery
Type: Li-Ion 3582 mAh
Charging: Wired, PD2.0, 50% in 30 min
25W wireless (MagSafe), 15W wireless (China only)
15W wireless (Qi2)
4.5W reverse wired
Misc
Colors: Black Titanium, White Titanium, Natural Titanium, Desert Titanium
Models: A3293, A3083, A3292, A3294, iPhone17,1
SAR 1.09 W/kg (head) 1.19 W/kg (body)
SAR EU 1.24 W/kg (head) 1.48 W/kg (body)
