Network
Technology: GSM / CDMA / HSPA / EVDO / LTE / 5G
2G bands: GSM 850 / 900 / 1800 / 1900
CDMA 800 / 1900
3G bands: HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100
CDMA2000 1xEV-DO
4G bands: 1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 30, 32, 34, 38, 39, 40, 41, 42, 46, 48, 53, 66 - A3106
1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 32, 34, 38, 39, 40, 41, 42, 46, 48, 53, 66, 71 - A2849
1, 2, 3, 4, 5, 7, 8, 11, 12, 13, 14, 17, 18, 19, 20, 21, 25, 26, 28, 29, 30, 32, 34, 38, 39, 40, 41, 42, 46, 48, 53, 66, 71 - A3105
1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 30, 32, 34, 38, 39, 40, 41, 42, 46, 48, 66 - A3108
5G bands: 1, 2, 3, 5, 7, 8, 12, 20, 25, 26, 28, 30, 38, 40, 41, 48, 53, 66, 70, 77, 78, 79 SA/NSA/Sub6 - A3106
1, 2, 3, 5, 7, 8, 12, 14, 20, 25, 26, 28, 29, 30, 38, 40, 41, 48, 53, 66, 70, 71, 77, 78, 79, 258, 260, 261 SA/NSA/Sub6/mmWave - A2849
1, 2, 3, 5, 7, 8, 12, 14, 20, 25, 26, 28, 29, 30, 38, 40, 41, 48, 53, 66, 70, 71, 75, 76, 77, 78, 79 SA/NSA/Sub6 - A3105
1, 2, 3, 5, 7, 8, 12, 20, 25, 26, 28, 30, 38, 40, 41, 48, 66, 70, 77, 78, 79 SA/NSA/Sub6 - A3108
Speed: HSPA, LTE, 5G, EV-DO Rev.A 3.1 Mbps
Launch
Announced: 2023, September 12
Status: Available. Released 2023, September 22
Body
Dimensions: 159.9 x 76.7 x 8.3 mm (6.30 x 3.02 x 0.33 in)
Weight: 221 g (7.80 oz)
Build: Glass front, glass back, titanium frame (grade 5)
SIM · Nano-SIM + eSIM + eSIM (max 2 at a time; International)
· eSIM + eSIM (8 or more, max 2 at a time; USA)
· Nano-SIM + Nano-SIM (China)
IP68 dust tight and water resistant (immersible up to 6m for 30 min)
Apple Pay (Visa, MasterCard, AMEX certified)
Display
Type: LTPO Super Retina XDR OLED, 120Hz, HDR10, Dolby Vision, 1000 nits (typ), 2000 nits (HBM)
Size: 6.7 inches, 110.2 cm2 (~89.8% screen-to-body ratio)
Resolution: 1290 x 2796 pixels, 19.5:9 ratio (~460 ppi density)
Protection: Ceramic Shield glass
Platform
OS: iOS 17, upgradable to iOS 26
Chipset: Apple A17 Pro (3 nm)
CPU: Hexa-core (2x3.78 GHz + 4x2.11 GHz)
GPU: Apple GPU (6-core graphics)
Memory
Card slot: No
Internal: 256GB 8GB RAM, 512GB 8GB RAM, 1TB 8GB RAM
NVMe
Main Camera
Triple: 48 MP, f/1.8, 24mm (wide), 1/1.28", 1.22µm, dual pixel PDAF, sensor-shift OIS
12 MP, f/2.8, 120mm (periscope telephoto), 1/3.06", 1.12µm, dual pixel PDAF, 3D sensor‑shift OIS, 5x optical zoom
12 MP, f/2.2, 13mm, 120˚ (ultrawide), 1/2.55", 1.4µm, dual pixel PDAF
TOF 3D LiDAR scanner (depth)
Features: Dual-LED dual-tone flash, HDR (photo/panorama)
Video: 4K@24/25/30/60fps, 1080p@25/30/60/120/240fps, 10-bit HDR, Dolby Vision HDR (up to 60fps), ProRes, 3D (spatial) video, stereo sound rec.
Selfie camera
Single: 12 MP, f/1.9, 23mm (wide), 1/3.6", 1.0µm, PDAF, OIS
SL 3D, (depth/biometrics sensor)
Features: HDR, Dolby Vision HDR
Video: 4K@24/25/30/60fps, 1080p@25/30/60/120fps, gyro-EIS
Sound
Loudspeaker: Yes, with stereo speakers
3.5mm jack: No
Comms
WLAN: Wi-Fi 802.11 a/b/g/n/ac/6e, tri-band, hotspot
Bluetooth: 5.3, A2DP, LE
Positioning GPS (L1+L5), GLONASS, GALILEO, BDS, QZSS, NavIC
NFC: Yes
Radio: No
USB: USB Type-C 3.2 Gen 2, DisplayPort
Features
Sensors: Face ID, accelerometer, gyro, proximity, compass, barometer
Ultra Wideband (UWB) support (gen2 chip)
Emergency SOS, Messages and Find My via satellite
Battery
Type: Li-Ion 4441 mAh
Charging: Wired, PD2.0, 50% in 30 min
15W wireless (MagSafe)
15W wireless (Qi2) - requires iOS 17.2 update
4.5W reverse wired
Misc
Colors: Black Titanium, White Titanium, Blue Titanium, Natural Titanium
Models: A2849, A3105, A3106, A3108, iPhone16,2
SAR 1.07 W/kg (head) 1.11 W/kg (body)
SAR EU 0.98 W/kg (head) 0.98 W/kg (body)
